    Repair log: Last Action Hero (Data East, 1993)

    1993 Data East Last Action Hero Repair log

    Repair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!


    Image description


    πŸ€ It's been a while since I've had to repair a insect and rodent sanctuary. The cabinet and backbox of this game were full of wasp nests and rat poop. So this game needed a pretty deep clean before I could tackle anything else! The primary issue was the game would not boot. A combination of destroyed fuse clips and leaking capacitors on the power supply were the culprits in this case.


    Once the game booted up, I could focus on the many other issues. Unfortunately the rat poop was not the only evidence they left behind; they also chewed through a bunch of wiring at the base of the cabinet as well as in the backbox. This resulted in a lot of game features not working including some lamps, flashers, the shaker motor, and a couple of switches. Those little teeth sure do a lot of damage!


    A few small issues to round out the repair. The balls were getting stuck in the trough. The trough was very rusty, and the balls were getting caught on the rust spots. Some rust converter and a clean made things nice and smooth again.


    Most of the insert lamps above the flippers were out. Bulbs, sockets and connectors were eliminated as the cause. Turns out, these lamps are all in the same column, driven by Q70 on the MPU board. Q70 had failed. Once replaced, the lamps were turning on again.


    A bunch of other parts needed replacing. New drop target. Couple of new switches. New balls. New rubber rings. New lamps.


    Machine is almost at 100% now bar a couple of minor issues, and is fully playable, which is much better than it was before I turned up. Ready for "action"! 🎬


  • Published on

    Repair log: PinStation virtual pinball

    PinStation Repair log Virtual pinball

    Repair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!

    ο»Ώ


    πŸ‘ Yes, we fix virtual pinball machines too! Service call today for a PinStation virtual pinball machine. Computer was not booting up. New battery installed and BIOS settings updated to get the machine going again.


    Many people assume that since (most) virtual pinball machines have no mechanical components, that they are maintenance-free and will run forever. Unfortunately not so! Most virtual machines are run on computers, which suffer all of the normal failure modes that computers do such as batteries going flat, hard drive failures, and software issues.


    The most important tool when working on real pinball machines is a screwdriver. On virtual machines, it's a keyboard! ⌨️

  • Published on

    Repair log: Judge Dredd (Bally, 1993)

    1993 Bally Judge Dredd Repair log

    Repair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!


    Image description


    Lots of work involved in preparing this machine for sale! First, a thorough clean. This necessitated taking all of the ramps off the playfield so you can access all ball areas at the top of the playfield. There was some Mylar lifting in this area so that had to be removed.


    Next, the drop targets. The "J" target was not staying up. The targets are meant to rest on a plastic shelf which keeps them in the "up" position. Somebody had installed a homemade version of this part which had cracked. Correct part installed and assembly rebuilt.


    Next, the subway entrance. There were some lamps missing here which were reinstalled. There are also two small wire ball guides on either side of the hole which guide the ball into the subway. They had fallen out at some point and were in the base of the cabinet. They were re-tensioned and glued back into place. New rubbers installed while I had this bit apart.


    Next, the lamps. Plenty not working, particularly those on the lamp boards. Cracked solder is common on these, particularly the lamps in sockets which are parallel to the playfield. Most of these needed resoldering.


    Next, the Deadworld. It kept spinning and wouldn't stop to allow the magnet to pick up the balls. One of the optos under the playfield which reports the Deadworld position was not working. It was fouled up with dust and dirt which were keeping it "closed". Cleaned and back in action.


    Finally, the flippers. Upper right flipper to be exact. This one was intermittently weak. A quick rebuild did not help. Test mode revealed the flipper switch was flaky. This switch is on an opto board. Rebuilt the connector and reflowed solder on the board but this didn't fix it. Turns out, the opto itself was on the way out. Replaced it and all was good again in Mega City One.


  • Published on

    Repair log: Funhouse (Williams, 1990)

    1990 Funhouse Repair log Williams

    Repair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!


    Image description


    Another Rudy with various issues! First was the display. It wasn't working except for the faintest edge of a letter or number every so often. After some probing I found that the negative high voltage display rail was too low (~20v). No improvement after new caps and transistors. The fault was with R48 which was preventing this half of the regulator circuit turning on. With the circuit rebuilt the display was back in service.


    Lamps were next. Lots of controlled (insert) lamps were dead. Mixture of new wedge globes and new sockets needed here. The playfield general illumination was also not working, while the backbox lamps were fine. The lamps themselves were all good, so the problem was on the driver board. The power input connector at J115 had been hacked up a bit with a small Molex connector used to replace a burned section. The crimps in this connector had failed, which cut off all power to the playfield GI. New crimps and the playfield was bright again.


    Last, the lower left flipper was a bit weak, and sticking up sometimes. Two issues here. The first was a dirty and gummed up flipper mechanism. Once cleaned and resleeved, power was back. But the flipper would still stick up sometimes. The contact points on the high-current flipper switch contacts were sticking. New flipper switch went in and the sticking stopped.


    A quick clean to finish up and Rudy was back to his old tricks!


  • Published on

    Repair log: Black Pyramid (Bally, 1984)

    1984 Bally Black Pyramid Repair log

    Repair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!

    ο»Ώ

    Image description


    This Black Pyramid wasn't booting up anymore. The MPU board exhibited corrosion from a leaking battery. Voltages were all good, so something in the reset circuitry on the MPU was stuffed. Took the board in for rehab, removed affected components, treated the alkali residue, sanded everything back, and repopulated the board. Now it's booting up reliably again.


    There were a few more tasks to get this game back to 100%. The solenoid driver board got some fresh capacitors and voltages were adjusted. Installed new rubber rings on the playfield. Replaced a broken drop target. (These linear drop target mechs are a breeze to work on!) Reflowed solder on the auxiliary lamp driver board to get some lamps going again. A couple of switch capacitors had died, rendering the switches inoperable. Replaced those too. After all that, it was good to go again!


  • Published on

    Repair log: The Addams Family (Bally, 1992)

    1992 Bally Repair log The Addams Family

    ο»ΏRepair logs are quick summaries of workshop and on-site repairs. If your machine needs a service, πŸ“¬ Contact Us to discuss how we can help!

    ο»Ώ

    Image description


    This Addams Family had a bit of a wonky bookcase assembly. It wasn't level with the playfield and was trapping balls on its bottom edge. After taking it apart, a few broken parts revealed themselves including the bookcase frame, base, and one of the actuators driven by the bookcase motor. Perfect opportunity to service the mechanism and replace all of the broken parts! New parts ordered, installed, and working great now.


    A few minor repairs were enacted on other parts of the game as well including a new battery holder for the CPU board, replacement of some lamp sockets, and installation of a strip of LED lights (had to create a small custom wiring harness for them).
